Wood Router 80 Watt Co2 Laser Tube For Laser Engraving Machine
Product quick detail:
1. the new jog distance, can make the optical head accurately move
to the position we need.
2. The reflective lens and focusing lens of the optical path system
use a full set of imported laser lenses, which greatly saves the
heat loss of the laser in air propagation.
3. It adopts imported three-phase stepping motor and drive system,
equipped with high-precision imported linear guide rails; makes the
perfect combination of motor, drive and guide rail, greatly
improving the accuracy and speed of the machine.
4. the industry's leading continuous, fast curve cutting function;
ordinary model 12m / min, advanced model 40m / min.
5. The control system integrates two algorithms of high-speed
cutting and precision cutting, which are suitable for different
user groups pursuing fast cutting and precision cutting.
6. The all-optical isolation system is designed with high-speed
differential input and output circuits. The signal is not distorted
during long transmission and has strong anti-interference ability.
7. Manually move the car speed, which can be set on the control
panel (unit: mm/s).
| Machine model | Laser Engraving Machine CO2 |
| Laser type | Sealed CO2 laser tube |
| Laser power | 40W/60W/80W/100W |
| Cooling mode | Circulating water cooling |
| Laser power control | 0-100% software control |
| Control system | DSP offline control system |
| Max. engraving speed | 60000mm/min |
| Max cutting speed | 50000mm/min |
| Repetition accuracy | ≤±0.01mm |
| Min. Letter | Chinese:1.5mm, English:1mm |
Product description
This model is a little wide desktop laser engraving machine,
applied to a variety of materials of engraving and cutting, carving
effect is good, independently regulate the carving depth, cutting
edge smooth and no burr, no secondary grinding processing.
The device from software design, mechanical structure, electrical
system and accessories selection always is for the purpose of
customer demand
Product advantage
1.It can cut many non-metallic materials such as cloth, leather,
wood, acrylic, etc., and it is widely used in the industry.
2. with cutting, engraving (including slope carving) and scanning
function, to achieve a multi-purpose machine. Wide application
industry.
3. Apply ultra-fine cutting technology, with higher cutting
precision, smaller jitter, smoother curve and finer engraving.
4. high-speed USB2.0 interface, communication is more stable, the
motherboard carries a large-capacity memory chip, can store up to
128 files, can easily achieve mass production of 128 different
products.
5. support U disk function, U disk can copy files with the
motherboard, complete full offline operation, achieve file sharing
to improve work efficiency.
6. using high-precision 32-bit floating-point DSP + FPG A dual-core
control, floating-point DSP clocked at up to 300MHZ, the overall
operating efficiency of the system improved.
7. Smooth S-type acceleration and deceleration control software
technology, the action is fast and stable, and the automatic light
compensation technology makes the different cutting parts achieve
the desired effect.
8. the maximum can be set 30S laser on / off light pauses the
puncture time, easy to cut the die.
9. Perfect power-off and continuous engraving function. When the
power is turned off for the second time, the graphics can achieve
good docking. It does not repeat the cutting to save time, and also
protects valuable materials from being cut.
10. you can set the operation of the border on the keyboard,
divided into three modes: light-cut border, light-off border, and
four corners.
Why choose the machine?
It's mainly used in advertising craft gift industry, garment
leather industry, automotive interiors, such as paper cutting
industry (leather, cloth, wood, bamboo, organic glass, plastic,
crystal and other non-metal materials.
