Certificated Tabletop Dot Pin Marking Machine With Marking Needle
Principle
The contents of the input to computer English character and
graphics printing, computer marking software convert the content of
digital control signal transmitted to the controller, drive and
print on the workpiece play consisting of a continuous lattice
character and graphics; the needle in the X Y two dimensional plane
trajectory according to the set, and print needle under the effect
of compressed air on the surface of the work piece to print out the
concave marks composed of dense lattice.
Application:
All kinds of mechanical parts, machine tools, hardware products,
metal pipes, gear, pump body, valves, fasteners, steel, instruments
and instruments. Metal marking, such as mechanical and electrical
equipment, etc
| model | Dot pin marking machine |
| weight | 50kg |
| Machinpower | <300w |
| Power supply | 220v/110v |
| Strokefre quency | 300times/s |
| Marking speed | 2-5 characters(2x2mm)/s |
| Marking depth | 0.01 to 1mm (Vary to the material) |
| Standard marking area | 80x40mm,130x30mm,140x80mm,200x200mm |
Usage method
Maintenance of the controller: after the power of the controller is
closed, the outer cover of the box is opened, and the air will be
cleaned with clean friendship competition air. In peacetime, more
attention should be paid to the dust prevention work outside the
chassis.
Product features
Needle hardness and life: 92HRA, life expectancy and workpiece
hardness, the general can use more than three months
FAQ
What do you do when the switch is damaged
1, when using the hand to press the origin switch, the marker head
still moves towards the origin point. At this time, please use
multimeter to measure whether the original switch is damaged or
not, if it is damaged, replace the original switch.
2, if the original switch condition, the corresponding line please
check the original switch, whether there is a circuit where the
reference air plug and the print head connection table "please
measure, if possible, to replace the interface board, control
board, replacing the 19 core print cable, 25 pin data cable
replacement
Design features
Domestic USB high-speed data interface, the data transmission is
faster and more stable.
With linear bearing structure, there is no transverse clearance,
and the positioning is more accurate and free.
After service
Technical training for operation and maintenance personnel;
(training content: the principle of equipment installation and
debugging and marking machine, composition and common knowledge of
computer. The computer programming, the electrical control
principle and the daily maintenance of the equipment and so on, and
carry on the actual operation. Equipment common troubleshooting
training, further familiarity with equipment, answering questions,
Packing and shipping
Packing by corrugated board boxes, Light weight, freight is
lower,shipping by air
| Delviery time | 7-15 working days |
| Type of shipping | Express or by sea |
| Terms of payment | T/T,credit card,,paypal |
| package size | 65x55x75cm |
| Gross weight | 50kg |
Chuke Factory
Chongqing Chuke Intelligent Machinery &Equipment Co.,Ltd
,is located in chongqing,china.since we founded in 2006s,we are
always devoted to provide reliable product and service to our
customer to build a great enterprise.after years of efforts,now our
bussiness involved fiber laser marking machine,co2 laser marking
machine,UV laser marking machine,Green laser marking machine,and so
on.
