The pneumatic marking needle is a computer controlled printing
needle moving in a two dimensional plane of X and Y. At the same
time, the printing needle is subjected to high frequency impact
motion under the action of compressed air, so that a mark with
certain depth is printed on the workpiece.
Application:
The marking needle is the only consumable of the pneumatic marking
machine. It is the accessory of the marking machine. It is a kind
of printing trademark, technical parameter, number, date, name and
so on on the metal sign of stainless steel, copper, aluminum and so
on.
Usage method
Print depth: the depth of a typeface is determined by the size of
the air pressure, the distance between the print needle and the
printed piece. (the depth of the print can be adjusted by adjusting
the size of the air pressure when the distance between the print
needle and the printed piece is constant. The pressure at this time
cannot be bottom to 0.4Mpa). (the depth of the print is adjusted by
adjusting the distance between the print needle and the printed
piece in the condition of constant pressure. In the use of gas
station air pressure to 0.5-0.7Mpa. Such as the use of air
compressor when the gas pressure is 0.5-0.6Mpa. Note: in the use of
air compressor air supply and space compressor should be selected
more than 3HP air compressor to ensure the stability of the air
pressure).
Product features
Diamond needle core
The needle is inlaid with diamond, the main hardness is higher than
HRC60 degrees, and it is suitable for the marking of special
hardness materials, such as alloy cutting tools, etc.
| type | marking needle |
| Size | 3mm |
| length | 56mm |
| Type | pneumatic marking needle |
FAQ
How many kinds of pneumatic marking needles are there at the first
moment? There are more than two hundred types of pneumatic marking
needles in the first moment, and what are the sizes and sizes of
the needles in different sizes?
The sealing ring spring 1 sets
Function
The marking needle shell color has red, yellow, green, blue, black,
marked needle shell plating color, not only beautiful but also can
effectively protect the shell
After service
One warranty for the whole machine.Three months for the marking
needle.
Packing and shipping
Packaging material: carton case with foam inside.
Shipping: 3-5 workdays shipping from China by
Air/Express(DHL,FedEx,UPS,EMS etc.)
| Delviery time | 1-3 working days |
| Type of shipping | Express |
| Terms of payment | T/T,credit card,western union,paypal |
| package size | 20x20x10cm |
| Gross weight | 0.5KG/5 piece |
